[Daim ntawv] Q-81S High-precision Fusion Splicer
Taw qhia
Lub high-precision fusion splicer, nrog high-ceev duab ua technology thiab tshwj xeeb precision positioning technology, yuav ua kom tiav tag nrho cov txheej txheem ntawm fiber ntau fusion splicing txiav nyob rau hauv 9 vib nas this.
Cov yam ntxwv ntawm lub teeb yuag, yooj yim nqa thiab yooj yim rau kev khiav lag luam, ceev splicing ceev thiab tsawg poob, nws yog tshwj xeeb tshaj yog haum rau optical fiber thiab cable tej yaam num, txij nkawm kev tshawb fawb thiab kev qhia nyob rau hauv kev sib txuas lus, xov tooj cua thiab TV, railway, petrochemical, hluav taws xob fais fab, tub rog thiab pej xeem kev ruaj ntseg thiab lwm yam kev sib txuas lus.
Lub tshuab no tsuas yog siv rau kev sib txuas ntawm cov khoom siv kho qhov muag, uas tuaj yeem txuas ntxiv nrog cov kab hluav taws xob zoo tib yam, jumpers thiab ntau hom ib leeg, ntau hom thiab dispersion-shifted quartz optical fibers nrog cladding txoj kab uas hla ntawm 80µm-150µm.
Nco ntsoov: Khaws nws kom huv si thiab tiv thaiv kev vibrations thiab shocks.
Technical Indicators
| Muaj feem xyuam rau optical fiber | SM (G.652 & G.657), MM (G.651), DS (G.653), NZDS (G.655) thiab tus kheej-txhais kho qhov muag fiber ntau hom |
| Splicing poob | 0.02dB (SM), 0.01dB (MM), 0.04dB (DS/NZDS) |
| Rov Los Los | Tshaj 60dB |
| Hom splicing ntev | 9 nqi |
| Lub sij hawm cua sov | 26 vib nas this (configurable cua sov lub sij hawm thiab adjustable cua sov kub) |
| Optical fiber ntau sib npaug | Precise alignment, fiber core alignment, cladding alignment |
| Optical fiber ntau | Cladding txoj kab uas hla 80 ~ 150µm, txheej txheej txoj kab uas hla 100 ~ 1000µm |
| Txiav ntev | Txheej txheej hauv qab 250µm: 8 ~ 16mm;Txheej txheej 250 ~ 1000µm: 16mm |
| Kev ntsuas nruj | Standard 2N (yeem) |
| Optical fiber ntau clamp | Multi-function clamp rau liab qab fiber ntau, tail fiber, jumpers, tawv kab;Hloov clamp siv tau rau SC thiab lwm yam txuas rau ntau yam FTTx optical fiber thiab cable. |
| Amplification factor | 400 zaug (X axis lossis Y axis) |
| Thaum tshav kub kub shrink Bush | 60mm \ 40mm thiab ib lub pob me me |
| Zaub | 3.5 nti TFT xim LCD zaub Reversible, yooj yim rau kev ua haujlwm bi-directional |
| Sab nraud interface | USB interface, yooj yim rau cov ntaub ntawv rub tawm thiab hloov kho software |
| Splicing hom | 17 pawg ntawm kev ua haujlwm hom |
| Hom cua sov | 9 pawg hom kev ua haujlwm |
| Splicing poob cia | 5000 qhov tseeb splicing tshwm sim tau muab cia rau hauv lub built-in cia |
| Built-in roj teeb | Txhawb kev txuas txuas ntxiv thiab cua sov tsis pub tsawg dua 200 zaug |
| Fais fab mov | Lub roj teeb built-in lithium 11.8V muab lub zog, them lub sijhawm≤3.5h; Sab nraud adapter, input AC100-240V 50 / 60HZ, tso zis DC 13.5V / 4.81A |
| Kev txuag hluav taws xob | 15% ntawm lub zog ntawm lithium roj teeb tuaj yeem txuag tau hauv ib puag ncig ib puag ncig |
| Ua haujlwm ib puag ncig | Kub: -10 ~ + 50 ℃, Humidity: ＜95% RH (tsis condensation), Ua haujlwm qhov siab: 0-5000m, Max.cua ceev: 15m / s |
| Sab nrauv | 214mm (ntev) x 136mm (dav) x 109.5mm (siab) |
| Teeb pom kev zoo | Yooj yim rau kev teeb tsa fiber ntau optical thaum yav tsaus ntuj |
| Qhov hnyav | 1.21Kg (excl. roj teeb), 1.5Kg (nrog rau roj teeb) |
